EC Type can be used at high pressure by appropriately reducing excessive water pressure applied to Face.

  It is a seal tailored to DIN24960 with Multi Spring.

• General chemical applications oil refining, petrochemical, and pharmaceutical industries.
• Suitable for use with corrosive fluid.
• By choosing suitable component materials, the seals can be adapted to operate with a wide range of liquids and operating conditions.
• Mechanical drive design reduces slippage on shaft and sleeve to eliminate galling and premature wear.
• Lapping process results in high precision finish with optimal flatness.
• Compact design permits use in all types of rotating equipment, centrifugal pumps.
• The applied design can be used in a mixers and agitators.

• Temperatures : -40 ℃ to 180 ℃
• Pressure : 40 barG
• Speed : Up to 23 m/s

•   Compact Designs
•   PTFE V-Ring Secondary Seal
•   Multispring Design Ensures
•   DIN 24960/ISO 3069 Stuffing Box Fit
